2-25
LUBRICATION POINTS AND LUBRICANT TYPES
SPEC
EAS00032
CHASSIS
Lubrication point
Lubricant
Steering bearings and bearing races (upper and lower)
Front wheel oil seal (right and left)
Rear wheel oil seal
Front axle shaft
Rear wheel drive hub oil seal
Rear wheel drive hub mating surface
Rear axle shaft
Rear brake pedal shaft
Sidestand pivoting point and metal-to-metal moving parts
Link and sidestand switch contact point
Sidestand hook and spring
Throttle grip inner surface
Brake lever pivoting point and metal-to-metal moving parts
Clutch lever pivoting point and metal-to-metal moving parts
Relay arm, connecting rod and rear shock absorber collar
Pivot shaft
Rear frame thread
Swingarm pivot bearing
Swingarm head pipe end, oil seal and bush
Oil seal (relay arm, connecting arm and rear shock absorber)
Engine mount bolts (rear upper and lower)
Seat lock assembly
Shift pedal shaft
Shift shaft joint
