CHAS
29
EAS00613
FRONT BRAKE CALIPERS
Order Job / Part Q’ty Remarks
Removing the front brake calipers Remove the parts in the order listed.
N
TE:
The following procedure applies to both of
the front brake calipers.
Brake fluid Drain.
Refer to “BLEEDING THE HYDRAULIC
BRAKE SYSTEM”.
1 Union bolt 1
2 Copper washer 2
3 Brake hose 1
4 Brake caliper 1
For installation, reverse the removal
procedure.
30 Nm (3.0 m•kg, 22 ft•lb)
6 Nm (0.6 m•kg, 4.3 ft•lb)
35 Nm (3.5 m•kg, 25 ft•lb)
FRONT AND REAR BRAKES
To Next Page
