5-6
ENGINE
ENG
45 Nm (4.5 mSkg, 33 ftSlb)
NOTE:
45 Nm (4.5 mSkg, 33 ftSlb)
NOTE:
7 Nm (0.7 mSkg, 5.1 ftSlb)
NOTE:
EAS00192
INSTALLING THE ENGINE
1. Install:
S engine bracket
1
(to the engine)
S engine mounting adjust bolts
(temporary tighten)
2. Install:
S rear engine mounting bolts
1
S Lubricate the rear engine mounting bolt
threads with lithium-soap-based grease.
3. Install:
S right front engine mounting bolts
1
(temporary tighten)
S left front engine mounting bolts
2
First tighten the rear side engine mounting bolt.
4. Tighten:
S engine mounting adjust bolts
S First tighten the lower engine mounting adjust
bolt.
S Use the pivot shaft wrench
1
and pivot shaft
wrench adapter
2
to tighten the engine
mounting adjust bolts.
To Next Page
