2-1
1
CHASSIS SPECIFICA
TIONS
SPEC
CHASSIS SPECIFICA
TIONS
Item
Standard
Limit
Frame
Frame type
Caster angle
T
rail
Diamond
24
_
86 mm (3.39 in)
SSS
SSS
SSS
Front wheel
Wheel type
Rim
Size
Material
Wheel travel
Wheel runout
Max. radial wheel runout
Max. lateral wheel runout
Cast wheel
17 M
/
C
MT3.50
Aluminum
120 mm (4.72 in)
SSS
SSS
SSS
SSS
SSS
SSS
1 mm (0.04 in)
0.5 mm (0.02 in)
Rear wheel
Wheel type
Rim
Size
Material
Wheel travel
Wheel runout
Max. radial wheel runout
Max. lateral wheel runout
Cast wheel
17 M
/
C
MT5.50
Aluminum
120 mm (4.72 in)
SSS
SSS
SSS
SSS
SSS
SSS
1 mm (0.04 in)
0.5 mm (0.02 in)
Front tire
T
ire type
Size
Model (manufacturer)
T
ire pressure (cold)
0
X
90 kg (0
X
198 lb)
90
X
193 kg (198
X
426 lb)
(USA except for CAL)
90
X
192 kg (198
X
423 lb)
(CAL)
High-speed riding
Min. tire tread depth
T
ubeless
120
/
60 ZR17 M
/
C (55W)
Pilot SPOR
T N (MICHELIN)
D208FL (DUNLOP)
250 kPa (2.5 kgf
/
cm
2
, 2.5 bar
, 35.6 psi)
250 kPa (2.5 kgf
/
cm
2
, 2.5 bar
, 35.6 psi)
250 kPa (2.5 kgf
/
cm
2
, 2.5 bar
, 35.6 psi)
250 kPa (2.5 kgf
/
cm
2
, 2.5 bar
, 35.6 psi)
SSS
SSS
SSS
SSS
SSS
SSS
SSS
SSS
1.6 mm
(0.06 in)
