4-63
Order Job/Part Q’ty Remarks
1
2
3
4
5
6
7
Removing the under bracket
Front wheel
Front brake calipers
Front fork legs
Front fender
Handlebars
Fuel tank
Air filter case
Main switch coupler
Steering stem nut
Washer
Upper bracket
Under bracket panel
Lock washer
Upper ring nut
2
1
1
1
1
1
1
Remove the parts in the order listed.
Refer to “HANDLEBARS”.
Refer to “FUEL TANK” in chapter 3.
Refer to “AIR FILTER CASE” in chapter
3.
Disconnect
Refer to “FRONT FORK”.
Refer to “FRONT WHEEL AND BRAKE
DISCS”.
26 Nm (2.6 mSkg, 19 ftSlb)
23 Nm (2.3 mSkg, 17 ftSlb)
113 Nm (11.3 mSkg, 82 ftSlb)
52 Nm (5.2 mSkg, 38 ftSlb)
14 Nm (1.4 mSkg, 10 ftSlb)
1st
2nd
STEERING HEAD
CHAS
EAS00676
STEERING HEAD
UNDER BRACKET
