5-18
Order
Job
/
Part
Q’ty
Remarks
1
2
3
Removing the cylinder head
Intake and exhaust camshaft
Engine bracket
Cylinder head
Cylinder head gasket
Dowel pin
1
1
2
Remove the parts in the order listed.
Refer to “CAMSHAFTS”.
Refer to “ENGINE”.
For installation, reverse the removal
procedure.
12 Nm (1.2 m
S
kg, 8.7 ft
S
lb)
19 Nm (1.9 m
S
kg, 14 ft
S
lb)
50 Nm (5.0 m
S
kg, 36 ft
S
lb)
1st
2nd
CYLINDER HEAD
ENG
EAS00221
CYLINDER HEAD
