3-18
SYNCHRONIZING THE THROTTLE BODIES/
ADJUSTING THE ENGINE IDLING SPEED
CHK
ADJ
NOTE:
9. Measure:
S engine idling speed
Out of specification ! Adjust.
Make sure that the vacuum pressure is within
specification.
10. Stop the engine and remove the measuring
equipment.
11. Adjust:
S throttle cable free play
Refer to “ADJUSTING THE THROTTLE
CABLE FREE PLAY”.
Throttle cable free play
(at the flange of the throttle grip)
6 X 8 mm (0.24 X 0.31 in)
12. Remove:
S digital tachometer
S vacuum gauge
13. Install:
S air filter case
Refer to “AIR FILTER CASE”.
S fuel tank
Refer to “FUEL TANK”.
S rider seat
Refer to “SEATS”.
EAS00052
ADJUSTING THE ENGINE IDLING SPEED
Prior to adjusting the engine idling speed, the
throttle bodies synchronization should be ad-
justed properly, and the engine should have ad-
equate compression.
1. Start the engine and let it warm up for several
minutes.
2. Install:
S digital tachometer
(to the ignition of cylinder #1)
3. Check:
S engine idling speed
Out of specification ! Adjust.
Engine idling speed
1,250 X 1,350 r/min
To Next Page
