–18–
ELECTRICAL COMPONENTS
ELEC
9 Speed sensor
10 Crankshaft position sensor
11 Cylinder identification sensor
12 Radiator fan motor relay
13 Headlight relay (on/off)
14 Headlight relay (dimmer)
1 Coolant temperature sensor
2 Intake air temperature sensor
3 Intake air pressure sensor
4 Lean angle cut-off switch
5 Atmospheric pressure sensor
6 ECU
7 Starting circuit cut-off relay
8 Turn signal relay
ELECTRICAL
ELECTRICAL COMPONENTS
