3-16
ADJUSTING THE VALVE CLEARANCE/
SYNCHRONIZING THE THROTTLE BODIES
CHK
ADJ
NOTE:
NOTE:
NOTE:
7. Install:
S all removed parts
For installation, reverse the removal procedure.
SYNCHRONIZING THE THROTTLE BODIES
Prior to synchronizing the throttle bodies, the
valve clearance and the engine idling speed
should be properly adjusted and the ignition tim-
ing should be checked.
1. Stand the motorcycle on a level surface.
Place the motorcycle on a suitable stand.
2. Remove:
S rider seat
Refer to “SEATS”.
S fuel tank
Refer to “FUEL TANK”.
S air filter case
Refer to “AIR FILTER CASE”.
3. Remove:
S synchronizing hose
1
4. Install:
S vacuum gauge
1
(onto the synchronizing hose)
S digital tachometer
(near the spark plug)
Vacuum gauge
90890-03094, YU-08030
To Next Page
