5-2
ENGINE
ENG
20 Nm (2.0 m
S
kg, 15 ft
S
lb)
20 Nm (2.0 m
S
kg, 15 ft
S
lb)
20 Nm (2.0 m
S
kg, 15 ft
S
lb)
Order
Job
/
Part
Q’ty
Remarks
1
2
3
Removing the exhaust pipe
Bottom cowling
Side cowlings
Muffler
Exhaust pipe assembly
Exhaust pipe gasket
1
1
4
Remove the parts in the order listed.
For installation, reverse the removal
procedure.
Refer to “COWLINGS” in chapter 3.
23 Nm (2.3 m
S
kg, 17 ft
S
lb)
EAS00189
EXHAUST PIPE
Manuals by Motomatrix / www.motomatrix.co.uk / The Solution For Lost Motorcycle Coded Keys
email: info@motomatrix.co.uk
330
