4-17
Order
Job
/
Part
Q’ty
Remarks
1
2
3
4
5
6
Removing the rear brake pads
Screw plug
Brake pad pin
Rear brake caliper
Brake pad shim
Brake pad
Bleed screw
1
2
1
4
2
1
Remove the parts in the order listed.
For installation, reverse the removal
procedure.
6 Nm (0.6 m
S
kg, 4.3 ft
S
lb)
28 Nm (2.8 m
S
kg, 20 ft
S
lb)
2.
5 Nm (0
.25 m
S
k
g
, 1
.
8 f
t
S
lb)
18 Nm (1.8 m
S
kg, 13 ft
S
lb)
23 Nm (2.3 m
S
kg, 17 ft
S
lb)
FRONT AND REAR BRAKES
CHAS
REAR BRAKE P
ADS
Manuals by Motomatrix / www.motomatrix.co.uk / The Solution For Lost Motorcycle Coded Keys
email: info@motomatrix.co.uk
266
