3-32
CHECKING THE FUEL AND BREATHER HOSES/
CHECKING THE CRANKCASE BREATHER HOSE
CHK
ADJ
NOTE:
CAUTION:
EAS00096
CHECKING THE FUEL AND BREATHER
HOSES
The following procedure applies to all of the fuel
and breather hoses.
1. Remove:
S rider seat
Refer to “SEATS”.
S fuel tank
Refer to “FUEL TANK”.
2. Check:
S breather hoses
1
S fuel hoses
2
Cracks/damage ! Replace.
Loose connection ! Connect properly.
Before removing the fuel hoses, place a few
rags in the area under where it will be removed.
3. Install:
S fuel tank
Refer to “FUEL TANK”.
S rider seat
Refer to “SEATS”.
EAS00098
CHECKING THE CRANKCASE BREATHER
HOSE
1. Remove:
S rider seat
Refer to “SEATS”.
S fuel tank
Refer to “FUEL TANK”.
2. Check:
S crankcase breather hose
1
Cracks/damage ! Replace.
Loose connection ! Connect properly.
Make sure the crankcase breather hose is
routed correctly.
3. Install:
S fuel tank
Refer to “FUEL TANK”.
S rider seat
Refer to “SEATS”.
