8-19
ST
ARTER MOTOR
ELEC
Order
Job
/
Part
Q’ty
Remarks
1
2
Removing the starter motor
Rider seat
Fuel tank
Left side cowling
Starter motor lead
Starter motor
1
1
Remove the parts in the order listed.
Refer to “SEA
TS” in chapter 3.
Refer to “FUEL T
ANK” in chapter 3.
Refer to “COWLINGS” in chapter 3.
For installation, reverse the removal
procedure.
10 Nm (1.0 m
S
kg, 7.2 ft
S
lb)
5 Nm (0.5 m
S
kg, 3.6 ft
S
lb)
EAS00767
ST
ARTER MOTOR
