8-18
S Check the entire starting system’s wiring.
Refer to “CIRCUIT DIAGRAM”.
S Is the starting system’s wiring properly con-
nected and without defects?
EAS00766
12. Wiring
YES NO
Properly connect or
repair the starting
system’s wiring.
The starting system
circuit is OK.
11. Start switch
S Check the start switch for continuity.
Refer to “CHECKING THE SWITCHES”.
S Is the start switch OK?
YES NO
Replace the right
handlebar switch.
EAS00764
10. Clutch switch
S Check the clutch switch for continuity.
Refer to “CHECKING THE SWITCHES”.
S Is the clutch switch OK?
YES NO
Replace the clutch
switch.
EAS00763
EAS00752
9. Sidestand switch
S Check the sidestand switch for continuity.
Refer to “CHECKING THE SWITCHES”.
S Is the sidestand switch OK?
YES NO
Replace the side-
stand switch.
ELECTRIC STARTING SYSTEM
ELEC
To Next Page
