3-58
CHECKING AND LUBRICATING THE CABLES/
LUBRICATING THE LEVERS AND PEDALS /
LUBRICATING THE SIDESTAND/LUBRICATING THE REAR SUSPENSION
CHK
ADJ
WARNING
NOTE:
EAS00170
CHECKING AND LUBRICATING THE
CABLES
The following procedure applies to all of the in-
ner and outer cables.
Damaged outer cable may cause the cable to
corrode and interfere with its movement. Re-
place damaged outer cable and inner cables
as soon as possible.
1. Check:
S outer cable
Damage ! Replace.
2. Check:
S cable operation
Rough movement ! Lubricate.
Recommended lubricant
Engine oil or a suitable cable
lubricant
Hold the cable end upright and pour a few drops
of lubricant into the cable sheath or use a suit-
able lubricating device.
EAS00171
LUBRICATING THE LEVERS AND PEDALS
Lubricate the pivoting point and metal-to-metal
moving parts of the levers and pedals.
Recommended lubricant
Lithium-soap-based grease
EAS00172
LUBRICATING THE SIDESTAND
Lubricate the pivoting point and metal-to-metal
moving parts of the sidestand.
Recommended lubricant
Lithium-soap-based grease
EAS00174
LUBRICATING THE REAR SUSPENSION
Lubricate the pivoting point and metal-to-metal
moving parts of the rear suspension.
Recommended lubricant
Molybdenum-disulfide grease
