3-40
ADJUSTING THE REAR BRAKE
CHK
ADJ
a
b
WARNING
WARNING
CAUTION:
EAS00110
ADJUSTING THE REAR BRAKE
1. Check:
S brake pedal position
(distance
a
bottom of the footrest bracket)
Out of specification ! Adjust.
Brake pedal position (below the
bottom of the footrest bracket)
7 X 11 mm (0.28 X 0.43 in)
2. Adjust:
S brake pedal position
a. Loosen the locknut
1
.
b. Turn the adjusting bolt
2
in direction
a
or
b
until the specified brake pedal position is ob-
tained.
Direction
Brake pedal is raised.
Direction Brake pedal is lowered.
After adjusting the brake pedal position,
check that the end of the adjusting bolt
c
is
visible through the hole
d
.
c. Tighten the locknut
1
to specification.
Locknut
16 Nm (1.6 mSkg, 12 ftSlb)
A soft or spongy feeling in the brake pedal
can indicate the presence of air in the brake
system. Before the vehicle is operated, the
air must be removed by bleeding the brake
system. Air in the brake system will consid-
erably reduce braking performance and
could result in loss of control and possibly
an accident. Therefore, check and, if neces-
sary, bleed the brake system.
After adjusting the brake pedal position,
make sure there is no brake drag.
