4-64
Order Job/Part Q’ty Remarks
8
9
10
11
12
13
14
15
16
Rubber washer
Lower ring nut
Under bracket
Bearing cover
Bearing inner race
Upper bearing
Lower bearing
Dust seal
Bearing outer race
1
1
1
1
2
1
1
1
2
For installation, reverse the removal
procedure.
26 Nm (2.6 mSkg, 19 ftSlb)
23 Nm (2.3 mSkg, 17 ftSlb)
113 Nm (11.3 mSkg, 82 ftSlb)
52 Nm (5.2 mSkg, 38 ftSlb)
14 Nm (1.4 mSkg, 10 ftSlb)
1st
2nd
STEERING HEAD
CHAS
To Next Page
