CHAS
30
EAS00615
Order
Job / P
ar
t
Q’ty
Remarks
Disassembling the fr
ont brake
caliper
s
Disassemble th
e par
ts in the order listed.
N
O
TE:
N
O
TE:
The f
ollo
wing procedure applies to both of
the front brak
e calipers
.
Brak
e pad clip
2
Brak
e pad pin
1
Brak
e pad spring
1
Brak
e pad
2
Brak
e caliper piston
4
Brak
e caliper pisto
n seal
8
Bleed scre
w
1
F
or assemb
ly
, rev
erse the disassembly
procedure.
5 Nm (0.5 m•kg, 3.6
ft•lb)
FRONT AND REAR BRAKES
