2-8
ENGINE SPECIFICATIONS
SPEC
Item Standard Limit
Connecting rods
Crankshaft-pin-to-big-end-bearing
clearance
Bearing color code
0.028 X 0.052 mm (0.0011 X 0.0020 in)
1 = Blue 2 = Black 3 = Brown 4 = Green
0.09 mm
(0.0035 in)
SSS
Crankshaft
Width A
Width B
Max. runout C
Big end side clearance D
Big end radial clearance
Small end free play
Crankshaft-journal-to-crankshaft-
journal-bearing clearance
Bearing color code
51.85 X 52.55 mm (2.04 X 2.06 in)
268.8 X 270.0 mm (10.58 X 10.63 in)
SSS
0.160 X 0.262 mm (0.0063 X 0.0103 in)
0.028 X 0.052 mm (0.0011 X 0.0020 in)
0.32 X 0.50 mm (0.01 X 0.02 in)
0.034 X 0.058 mm (0.0013 X 0.0023 in)
0 = White 1 = Blue 2 = Black
3 = Brown 4 = Green
SSS
SSS
0.03 mm
(0.0012 in)
SSS
SSS
SSS
0.10 mm
(0.0039 in)
SSS
Clutch
Clutch type
Clutch release method
Clutch release method operation
Operation
Clutch cable free play (at the end
of the clutch lever)
Friction plates
Color code
Thickness
Plate quantity
Color code
Thickness
Plate quantity
Clutch plates
Thickness
Plate quantity
Max. warpage
Thickness
Plate quantity
Max. warpage
Clutch springs
Free length
Spring quantity
Wet, multiple disc
Outer pull, rack and pinion pull
Cable operation
Left-hand operation
10 X 15 mm (0.39 X 0.59 in)
Brown
2.9 X 3.1 mm (0.114 X 0.122 in)
6
Purple
2.9 X 3.1 mm (0.114 X 0.112 in)
2
1.9 X 2.1 mm (0.07 X 0.08 in)
7
SSS
2.2 X 2.4 mm (0.086 X 0.095 in)
1
SSS
50 mm (1.97 in)
6
SSS
SSS
SSS
SSS
SSS
SSS
2.8 mm
(0.110 in)
SSS
SSS
2.8 mm
(0.110 in)
SSS
SSS
SSS
0.1 mm
(0.0039 in)
SSS
SSS
0.1 mm
(0.0039 in)
49 mm
(1.93 in)
SSS
