Rear brake hose union bolt
Sidestand bracket and frame
Front wheel axle shaft and bolt
Rear wheel axle nut
Front brake caliper and front fork
Front brake disc and front wheel
Rear brake disc and rear wheel
Rear wheel sprocket and rear wheel drive hub
Brake caliper bleed screw
Pinch bolt (front wheel axle)
M10
M10
M14
M24
M10
M6
M8
M10
M8
M8
30
61
91
110
40
18
30
100
6
18
3.0
6.1
9.1
11.0
4.0
1.8
3.0
10.0
0.6
1.8
22
44
66
80
29
13
22
72
4.3
13
See NOTE 2
1. First, tighten the ring nut to approximately 52 Nm (5.2 mSkg, 38 ftSlb) with a torque wrench, then
loosen the ring nut completely.
2. Retighten the lower ring nut to specification.
S Tighten wheel axle pinch bolts
2
and
1
to
specified torque.
S Retighten pinch bolt
2
to specified torque.
S Tap the outer side of the left fork leg with a rub-
ber mallet to align it with the end of the wheel
axle.
S Tighten wheel axle pinch bolts
4
and
3
to
specified torque.
S Retighten pinch bolt
4
to specified torque.
