3-28
MEASURING THE ENGINE OIL PRESSURE
CHK
ADJ
NOTE:
8 Nm (0.8 mSkg, 5.8 ftSlb)
6. Measure:
S engine oil pressure
(at the following conditions)
Engine oil pressure
240 kPa
(2.4 kg/cm
2
, 2.4 bar, 34.1 psi)
Engine speed
Approx. 6,600 r/min
Engine oil temperature
96_C (205_F)
Regarding the oil pressure as its own data may
fluctuate depending on the oil temperature and
viscosity, the oil pressure may fluctuate when
measuring. The following data should be used
only as a reference when measuring the engine
oil pressure.
Engine oil pressure
Possible causes
Below
