4-1
1
Order
Job
/
Part
Q’ty
Remarks
Disassembling the rear wheel
Collar
Bearing
Spacer
Oil seal
Circlip
Bearing
1
1
1
1
1
1
Disassemble the parts in the order listed.
For installation, reverse the disassembly
procedure.
1
2
3
4
5
6
REAR WHEEL AND BRAKE DISC
CHAS
EAS00560
Manuals by Motomatrix / www.motomatrix.co.uk / The Solution For Lost Motorcycle Coded Keys
email: info@motomatrix.co.uk
260
262
