4-37
Order
Job
/
Part
Q’ty
Remarks
Disassembling the rear brake caliper
Screw plug
Brake pad pin
Brake pad
Brake pad shim
Brake pad spring
Brake caliper piston
Brake caliper piston seal
Bleed screw
1
1
2
4
1
1
2
1
Disassemble the parts in the order listed.
For assembly
, reverse the disassembly
procedure.
1
2
3
6 Nm (0.6 m
S
kg, 4.3 ft
S
lb)
4
5
6
7
8
2.
5 Nm (0
.25 m
S
k
g
, 1
.
8 f
t
S
lb)
18 Nm (1.8 m
S
kg, 13 ft
S
lb)
FRONT AND REAR BRAKES
CHAS
EAS00617
Manuals by Motomatrix / www.motomatrix.co.uk / The Solution For Lost Motorcycle Coded Keys
email: info@motomatrix.co.uk
286
