4-74
Order
Job
/
Part
Q’ty
Remarks
10
11
12
13
Bearing
Spacer
Pivot shaft adjust bolt
Drive chain case
2
1
1
1
For installation, reverse the removal
procedure.
95 Nm (9.5 m
S
kg, 69 ft
S
lb)
6 Nm (0.6 m
S
kg, 4.3 ft
S
lb)
7 Nm (0.7 m
S
kg, 5.1 ft
S
lb)
16 Nm (1.6 m
S
kg, 12 ft
S
lb)
SWINGARM AND DRIVE CHAIN
CHAS
Manuals by Motomatrix / www.motomatrix.co.uk / The Solution For Lost Motorcycle Coded Keys
email: info@motomatrix.co.uk
323
