6-7
Order
Job
/
Part
Q’ty
Remarks
1
2
3
Removing the thermostat
Rider seat
Air filter case
Throttle body assembly
Coolant
Radiator inlet hose
Thermostat cover
Thermostat
1
1
1
Remove the parts in the order listed.
Refer to “SEA
TS” chapter 3.
Refer to “AIR FIL
TER CASE” in chapter 3.
Refer to “THROTTLE BODIES” in chapter
7.
Drain.
Refer to “CHANGING THE COOLANT” in
chapter 3.
For installation, reverse the removal
procedure.
12 Nm (1.2 m
S
kg, 8.7 ft
S
lb)
THERMOST
A
T
COOL
EAS00461
THERMOST
A
T
