5.5 Functions and Settings for the /S-ON (Servo ON) Signal
5.5.1 Function of the /S-ON (Servo ON) Signal
5-17
5
Basic Functions That Require Setting before Operation
5.5 Functions and Settings for the /S-ON (Servo ON) Signal
The /S-ON (Servo ON) signal is used to enable Servomotor operation.
This section describes the function of and settings for the /S-ON signal.
5.5.1 Function of the /S-ON (Servo ON) Signal
You can use Pn50A = n.X (/S-ON (Servo ON) Signal Allocation) to allocate the /S-ON sig-
nal to a different input signal terminal. Refer to the following section for details on input signal
allocation.
6.1.1 Input Signal Allocations on page 6-5
5.5.2 Setting to Keep the Servo ON and Supply Power to the
Motor Continuously
You can set Pn50A = n.X (/S-ON (Servo ON) Signal Allocation) to 7 (The signal is always
active) to keep the servo ON and supply power to the motor continuously.
Typ e Signal Connector Pin No. Signal Status Function
Input /S-ON
CN1-40
(default setting)
ON (closed)
Power is supplied to the Servomo-
tor to enable operation.
OFF (open)
Power supply to the Servomotor is
stopped and operation is disabled.
1. Always input the /S-ON signal before you input a speed, position, or torque reference to start
the Servomotor. Never input the reference first and then use the /S-ON signal or turn ON the
AC power supply to start the Servomotor. Doing so will degrade internal elements and may
cause an accident.
2. Input the /S-ON signal while the Servomotor is stopped. You cannot turn ON the servo while
the Servomotor is operating.
Important
Parameter Meaning When Enabled Classification
Pn50A
n.0
(default setting)
The S-ON signal is active when CN1-40 input
signal is ON (closed).
After restart Setup
n.
7
The signal is always active.
(The /S-ON signal is always active.)
1. If you set this parameter to keep the servo ON continuously, power will be supplied to the
motor as soon the main circuit power supply to the SERVOPACK is turned ON. If there is
already a speed, position, or torque reference input, the Servomotor or machine may perform
unexpected operation. Always implement safety measures.
2. If a resettable alarm occurs and operation is disabled (power is not supplied to the motor),
operation will be automatically enabled (power will be supplied to the motor) when the alarm is
reset. If you set this parameter to keep the servo ON continuously, the Servomotor or machine
may perform unexpected operation when an alarm is reset.
Important

YASKAWA SGD7S series Specifications

General

Series	SGD7S
Safety	STO (Safe Torque Off)
Humidity	90% RH or less (non-condensing)
Control Method	PWM Control
Communication	EtherCAT, MECHATROLINK-III, MECHATROLINK-II
Output Power	0.1 kW to 15 kW
Feedback System	Incremental encoder, Absolute encoder
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Overheating, Encoder Error
Ambient Temperature	0 to 55°C
Storage Temperature	-20 to 85°C
Vibration Resistance	5.9 m/s²
Installation	Panel mounted
Certifications	CE, UL, cUL
