3.5 Monitoring the Installation Environment
3-7
3
SERVOPACK Installation
3.5 Monitoring the Installation Environment
You can use the SERVOPACK Installation Environment Monitor parameter to check the operat-
ing conditions of the SERVOPACK in the installation environment.
You can check the SERVOPACK installation environment monitor with either of the following
methods.
• Using the SigmaWin+: Life Monitor - Installation Environment Monitor - SERVOPACK
• Panel Operator or Digital Operator: Un025 (Installation Environment Monitor [%])
Implement one or more of the following actions if the monitor value exceeds 100%.
• Lower the surrounding temperature.
• Decrease the load.
The value of the SERVOPACK Installation Environment Monitor parameter will increase by
about 10% for each 10°C increase in the ambient temperature.
Always observe the surrounding air temperature given in the SERVOPACK environment condi-
tions. Even if the monitor value is 100% or lower, you cannot use a SERVOPACK in a location
that exceeds the specified surrounding air temperature.
Information
Important

YASKAWA SGD7S series Specifications

General

Series	SGD7S
Safety	STO (Safe Torque Off)
Humidity	90% RH or less (non-condensing)
Control Method	PWM Control
Communication	EtherCAT, MECHATROLINK-III, MECHATROLINK-II
Output Power	0.1 kW to 15 kW
Feedback System	Incremental encoder, Absolute encoder
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Overheating, Encoder Error
Ambient Temperature	0 to 55°C
Storage Temperature	-20 to 85°C
Vibration Resistance	5.9 m/s²
Installation	Panel mounted
Certifications	CE, UL, cUL
