9.2 Monitoring SERVOPACK Status
9.2.1 Servo Drive Status
9-4
9.2 Monitoring SERVOPACK Status
9.2.1 Servo Drive Status
Use the following procedure to display the Servo Drive status.
• Start the SigmaWin+. The Servo Drive status will be automatically displayed when you go
online with a SERVOPACK.
The Servo Drive status is displayed.
The Servomotor type is displayed.

YASKAWA SGD7S series Specifications

General

Series	SGD7S
Safety	STO (Safe Torque Off)
Humidity	90% RH or less (non-condensing)
Control Method	PWM Control
Communication	EtherCAT, MECHATROLINK-III, MECHATROLINK-II
Output Power	0.1 kW to 15 kW
Feedback System	Incremental encoder, Absolute encoder
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Overheating, Encoder Error
Ambient Temperature	0 to 55°C
Storage Temperature	-20 to 85°C
Vibration Resistance	5.9 m/s²
Installation	Panel mounted
Certifications	CE, UL, cUL
