YASKAWA SGD7S series User Manual

6.6 Position Control
6.6.7 Reference Pulse Inhibition Function
6
Application Functions
6-39
6.6.7 Reference Pulse Inhibition Function
You can stop the SERVOPACK from counting the reference input pulses during position con-
trol. When this function is enabled, the SERVOPACK will ignore the reference pulse input.
/INHIBIT (Reference Pulse Inhibit) Signal
If you set the control method to switch between normal position control and position control
with reference pulse inhibition (Pn000 = n.B), the /INHIBIT signal is used as the Refer-
ence Pulse Inhibit signal (default setting).
 When Using the Default Input Signal Allocations (Pn50A = n.0)
 When Changing Input Signal Allocations (Pn50A = n.1)
If you set Pn000 = n.X (Control Method Selection) to 1, 5, 7, or 8, the /INHIBIT signal is
used as the Reference Pulse Inhibit signal for reference pulse inhibition.
Note: You must allocate the /INHIBIT signal to use it. Use Pn50D = n.X (/INHIBIT (Reference Pulse Inhibit
Input) Signal Allocation) to allocate the signal to a connector pin. Refer to the following section for details.
6.1.2 Output Signal Allocations on page 6-8
 Reference Pulse Inhibition Settings
To use reference pulse inhibition, set Pn000 = n.X (Control Method Selection) to 1, 5, 7 or
8.
Typ e Signal Connector Pin No. Signal Status Meaning
Input /INHIBIT
CN1-41
(default setting)
ON (closed) Counting the reference pulses is stopped.
OFF (open) The reference pulses are counted.
Typ e Signal Connector Pin No. Signal Status Meaning
Input /INHIBIT Must be allocated.
ON (closed) Counting the reference pulses is stopped.
OFF (open) The reference pulses are counted.
Parameter Control Method
Used Input Sig-
nals
When
Enabled
Classifica-
tion
Pn000
n.

1

Position control /INHIBIT
After restart
Setup
n.

5

Switching between internal set
speed control and position control
/INHIBIT
/SPD-A
/SPD-B
/SPD-D
/C-SEL
n.

7

Switching between position control
and speed control
/INHIBIT
/C-SEL
n.

8

Switching between position control
and torque control
/INHIBIT
/C-SEL
n.

B

Switching between normal position
control and position control with
reference pulse inhibition
/INHIBIT
Counting reference pulses can be inhibited only for position control.
Information

YASKAWA SGD7S series Specifications

General

Series	SGD7S
Safety	STO (Safe Torque Off)
Humidity	90% RH or less (non-condensing)
Control Method	PWM Control
Communication	EtherCAT, MECHATROLINK-III, MECHATROLINK-II
Output Power	0.1 kW to 15 kW
Feedback System	Incremental encoder, Absolute encoder
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Overheating, Encoder Error
Ambient Temperature	0 to 55°C
Storage Temperature	-20 to 85°C
Vibration Resistance	5.9 m/s²
Installation	Panel mounted
Certifications	CE, UL, cUL
