6.8 Absolute Encoders
6.8.3 Multiturn Limit Disagreement Alarm (A.CC0)
6-21
Operating Procedure
Use the following procedure to adjust the multiturn limit setting.
1.
Click the Servo Drive Button in the workspace of the Main Window of the SigmaWin+.
2.
Select Multiturn Limit Setting in the Menu Dialog Box.
The Multiturn Limit Setting Dialog Box will be displayed.
3.
Click the Continue Button.
Click the Cancel Button to cancel setting the multiturn limit.
The Main Window will return.
4.
Change the setting.
5.
Click the Writing into the Servopack Button.
6.
Click the OK Button.
To Next Page
