14.2 Alarm Displays
14.2.2 Troubleshooting Alarms
14-19
A.330:
Main Circuit
Power Supply
Wiring Error
(Detected when
the main circuit
power supply is
turned ON.)
The regenerative
resistor was discon-
nected when the
SERVOPACK power
supply voltage was
high.
Measure the resistance
of the regenerative
resistor using a measur-
ing instrument.
If you are using the regen-
erative resistor built into
the SERVOPACK, replace
the SERVOPACK.
If you are using an Exter-
nal Regenerative Resis-
tor, replace the External
Regenerative Resistor.
–
DC power was sup-
plied when an AC
power supply input
was specified in the
settings.
Check the power sup-
ply to see if it is a DC
power supply.
Correct the power supply
setting to match the
actual power supply.
page 5-13
AC power was sup-
plied when a DC
power supply input
was specified in the
settings.
Check the power sup-
ply to see if it is an AC
power supply.
Correct the power supply
setting to match the
actual power supply.
Pn600 (Regenerative
Resistor Capacity) is
not set to 0 and an
External Regenerative
Resistor is not con-
nected to one of the
following SERVO-
PACKs: SGD7S-
R70A, -R90A, -1R6A,
-2R8A, -R70F, -R90F,
-2R1F, o r -2R8 F.
Check it see if an Exter-
nal Regenerative Resis-
tor is connected and
check the setting of
Pn600.
Connect an External
Regenerative Resistor, or
if an External Regenera-
tive Resistor is not
required, set Pn600 to 0.
page 4-22,
page 5-52
A failure occurred in
the SERVOPACK.
–
The SERVOPACK may be
faulty. Replace the SER-
VOPACK.
–
Continued on next page.
Continued from previous page.
Alarm Number:
Alarm Name
Possible Cause Confirmation Correction Reference
