2.3 External Dimensions
2.3.3 DeviceNet Module External Dimensions and Connector Specifications
2-26
• Three-phase, 200 VAC: SGD7S-590A and -780A
2.3.3 DeviceNet Module External Dimensions and Connector
Specifications
• External Dimensions
• Connector Specifications
Note: The above connector or an equivalent is used.
Unit: mm
Approx. mass: 13.8 kg
Terminals
4 × M6
Terminals
8 × M6
Ground
terminals
2 × M6
(75) (75)136
64
(292.5)
390
375 ±0.5 (mounting pitch)
330 min.
7.5 30
390
4 × M6
Through hole
Exterior
Mounting Hole Diagram
244 min.
235
±
0.5
(mounting pitch)
260
4.5
8
260
Device Label Model Number of Pins Manufacturer
CN6 CM02-8DR5P-CF 5 DDK Ltd.
CN6
(24)
20
(24)
(89)
97
(8)
160
(28)
Approx. mass: 0.3 kg
Unit: mm
(43)
