Setting Up Your System
57
change take effect.
Web User Interface:
Network->Advanced->VLAN >PC Port->Priority
Phone User Interface:
Settings->Advanced (default password: admin) ->Network->VLAN->PC Port->Priority
To configure VLAN for Internet port via web user interface:
1. Click on Network->Advanced.
2. In the WAN Port block, select the desired value from the pull-down list of Active.
3. Enter the VLAN ID in the VID (1-4094) field.
4. Select the desired value (0-7) from the pull-down list of Priority.
5. Click Confirm to accept the change.
A dialog box pops up to prompt that the settings will take effect after a reboot.
6. Click OK to reboot the phone.
To configure VLAN for PC port via web user interface:
1. Click on Network->Advanced.
2. In the PC Port block, select the desired value from the pull-down list of Active.
3. Enter the VLAN ID in the VID (1-4094) field.
