6. Electrical installation
6.1 Safety
The installation includes the following items:
• “6.3 Grounding the drive system” on page 129
• “6.4 Internal wiring” on page 131
• “6.5 Cable entry systems” on page 135
• “6.8 Auxiliary power, control and serial communication cables”
on page 149
• “6.9 Heating cable” on page 166
Figure 6-1 Phase module on lift table
▲ DANGER ⚠
Hazardous voltage!
• Improper work could lead to life-threatening injury or death.
• The electrical installation must be carried out by qualified
personnel according to the site and equipment requirements and
the relevant electrical codes.
• When the electrical installation is completed, the main and auxiliary
power supply to the drive must not be switched on without the
consent of the ABB commissioning personnel.
• To prevent main and auxiliary power supply being switched on
during installation, take appropriate measures.
