06 ELECTRICAL INSTALLATION
3BHS212794 E01 REV M ACS6000 USER MANUAL 142/278
6.7 Power, ground and equipotential bonding
conductor cables§
The following sections describe how to prepare and route cables. For a
description on how to prepare the cable entries, see “6.6 Preparing cable
entry systems for TEU, ARU and EXU cabinets” on page 138.
See “Appendix C – Mechanical drawings” for information on:
• Project-specific cable entry
• Distance between point of cable entry and terminals or busbars
• Busbar and fastening hole dimensions
• Busbar designations
See “Appendix D – Wiring diagrams” for information on:
• Conventions for cross-reference and device identification
6.7.1 Determining the cable length
1. Determine the required length of a cable between the point of entry
and the connection point inside the cabinet.
2. Cut the cable to the required length before connection.
▲NOTICE
Risk of damage or malfunction!
• Waste inside the cabinet can cause damage or malfunction.
• If possible, DO NOT cut cables inside the terminal compartment.
• Retrieve any waste which accidentally dropped into the cabinet.
