3BHS212794 E01 REV M ACS6000 USER MANUAL 245/278
10 PREVENTIVE AND CORRECTIVE MAINTENANCE
Figure 10-16 Manual output isolation overview
(1) LSU1
(2) TEU1
(3) INU1
(4) CBU1
(5) BCU1
(6) INU2
(7) COU1
(8) LSU2
(9) WCU1
(10) Motor
(11) Busbar connectors (3 x) in TEU
(12) Busbar connectors (3 x) in COU1
(13) Lever for removing and fitting the
busbar connections
1
2 3 4 5 6 7 8 9
1 0
11 1 2
13
