3BHS212794 E01 REV M ACS6000 USER MANUAL 155/278
06 ELECTRICAL INSTALLATION
Figure 6-32 Cable route in COU (1000 mm) top cable entry
6.8.6.2 Bottom cable entry
1. Insert and route the cables as illustrated in Fig. 6-33 and Fig. 6-34.
Figure 6-33 Cable route in COU (600 mm) bottom cable entry
(1) Cable entry bottom
(2) Side view
(3) Detail
1
2
3
