08 OPERATION
3BHS212794 E01 REV M ACS6000 USER MANUAL 192/278
- INU 1 and other INUs (if present) are now in status “ARU NotRun”
5. (Drives with an ARU) Press the START key on the ARU control panel:
The ARU starts modulating, the control panel displays “Modulating”
and the status of the ARU changes to Modulating.
When the ARU has reached the status “ReadyRef”, the status of the
first INU and the other INUs change to “ReadyRun”
6. Enter the reference value.
7. Start the motor with the INU control panels.
After the motor has been magnetized, the motor speed ramps up to
the reference value.
While the motor is magnetizing, the run status message on the display
blinks. When the motor has finished magnetizing, the run status
message lights up permanently.
1 L -> 0.0 rpm 0
StateINU ARU NotRun
MOTOR SP 0.00 rpm
POWER 0.0 kW
1 L -> 0.0 rpm 0
StateINU ReadyRun
MOTOR SP 0.00 rpm
POWER 0.0 kW
1 L -> [600.0 rpm] 0
StateINU ReadyRun
MOTOR SP 0.00 rpm
POWER 0.0 kW
