3BHS212794 E01 REV M ACS6000 USER MANUAL 31/278
01 ABOUT THIS MANUAL
GTO Gate Turn-Off thyristor
GUSP Gate Unit Supply Power
HVD High Voltage Divider
I/O Input / Output
ID Induced Draft fan
IEC International Electrotechnical Commission
IFU Input Filter Unit
IGBT Insulated-Gate Bipolar Transistor
IGCT Integrated Gate-Commutated Thyristor
ISU Isolation Unit
IM Induction Motor
INT Interface circuit board
INU Inverter Unit
The INU converts the three DC voltages to the required AC
motor voltage. The unit is designed as a self-
commutated, 3-level voltage source inverter consisting of
three identical power modules.
I/O device Term of ABB’s S800 I/O system. An I/O device consists of
a module termination unit (MTU) and one I/O module.
I/O module Term of ABB’s S800 I/O system. The I/O module is an
active input or output device for digital or analog signals.
I/O station Term of ABB’s S800 I/O system. The I/O station typically
consists of a bus modem and several input and
output devices.
IOI Inverter Output Isolator
The IOI is a switching device that disconnects the inverter
from the motor.
IP Ingress Protection
The IP code specifies the degree of protection provided
by an enclosure.
Line voltage RMS voltage of the main power supply of the drive
LSU Line Supply Unit
The LSU rectifies the AC line voltage and supplies the
electrical energy to the DC link capacitors.
MCB Main Circuit Breaker
The MCB is a major protection device of the drive and the
main connection and disconnection point between the
main power supply and the drive.
MSM Main State Machine
MVD Medium Voltage Drive
Table 1-1 Terms and abbreviations (continued)
Term/Abbreviation Definition
