Source selection See Terms and abbreviations (page 132).
Other [bit]
Selected / uint32Selects the source of the negative speed reference enable
command. See parameter 20.23 Positive speed enable.
Negative speed
enable
20.24
Not selected / uint32Selects the source for a jog enable signal.
(The sources for jogging activation signals are selected by
parameters 20.26 Jogging 1 start source and 20.27 Jogging
2 start source.)
1 = Jogging is enabled.
0 = Jogging is disabled.
Note: Jogging can be enabled only when no start command
from an external control location is active. On the other
hand, if jogging is already enabled, the drive cannot be
started from an external control location (apart from inching
commands through fieldbus).
See section Jogging (page 61).
Jogging enable20.25
00Not selected
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO1 (11.2 DIO delayed status, bit 1).
DIO2
See Terms and abbreviations (page 132).
Other [bit]
Not selected / uint32
If enabled by parameter 20.25 Jogging enable, selects the
source for the activation of jogging function 1. (Jogging
function 1 can also be activated through fieldbus regardless
of parameter 20.25.)
1 = Jogging 1 active.
Note: If both jogging 1 and 2 are activated, the one that
was activated first has priority.
Jogging 1 start source20.26
00Not selected
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 02).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO2
