ABB ACS880 - Page 302

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
Source selection See Terms and abbreviations (page 132).
Other [bit]
Speed error / uint32Selects the input signal for the oscillation damping function.
Note: Before changing this parameter run-time, disable
the oscillation damping output using parameter 26.52.
Monitor the behavior of 26.58 before re-enabling the output.
Oscillation
compensation input
26.53
0
24.1 Used speed reference - unfiltered motor speed.
Note: This setting is not supported in scalar motor control
mode.
Speed error
1
1.11 DC voltage. (The value is internally filtered.)
DC voltage
31.0 Hz / real32Defines the center frequency of the oscillation damping
filter.
Set the value according to the number of oscillation peaks
in the monitored signal (selected by 26.53) per second.
Note: Before changing this parameter run-time, disable
the oscillation damping output using parameter 26.52.
Monitor the behavior of 26.58 before re-enabling the output.
Oscillation damping
frequency
26.55
10 = 1 Hz / 10 = 1 HzCenter frequency for oscillation damping.0.1 ... 60.0 Hz
180 deg / real32Defines a phase shift for the output of the filter.
Note: Before changing this parameter run-time, disable
the oscillation damping output using parameter 26.52.
Monitor the behavior of 26.58 before re-enabling the output.
Oscillation damping
phase
26.56
10 = 1 deg / 1 = 1 degPhase shift for oscillation damping function output.0...360 deg
1.0 % / real32Defines a gain for the output of the oscillation damping
function, ie. how much the output of the filter is amplified
before it is added to the torque reference.
Oscillation gain is scaled according to the speed controller
gain so that changing the gain will not disturb oscillation
damping.
Note: Before changing this parameter run-time, disable
the oscillation damping output using parameter 26.52.
Monitor the behavior of 26.58 before re-enabling the output.
Oscillation damping
gain
26.57
10 = 1 % / 10 = 1 %Gain setting for oscillation damping output.0.0 ... 100.0 %
302 Parameters
