ABB ACS880 - Page 303

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / real32Displays the output of the oscillation damping function.
This value is added to the torque reference (as allowed by
parameter 26.52 Oscillation damping out enable).
This parameter is read-only.
Oscillation damping
output
26.58
10 = 1 % / 1000 = 1 %Output of the oscillation damping function.-1600.000 ...
1600.000 %
- / real32Displays the value of torque reference source 1 (selected
by parameter 26.11 Torque ref1 source). See the control
chain diagram on page 631.
This parameter is read-only.
Torque reference act
1
26.70
- / -Value of torque reference source 1. For scaling, see
parameter 46.3.
-1600.0 ... 1600.0 %
- / real32Displays the value of torque reference source 2 (selected
by parameter 26.12 Torque ref2 source). See the control
chain diagram on page 631.
This parameter is read-only.
Torque reference act
2
26.71
- / -Value of torque reference source 2. For scaling, see
parameter 46.3.
-1600.0 ... 1600.0 %
- / real32Displays the torque reference after the function applied by
parameter 26.13 Torque ref1 function (if any), and after
selection (26.14 Torque ref1/2 selection). See the control
chain diagram on page 631.
This parameter is read-only.
Torque reference act
3
26.72
- / -Torque reference after selection. For scaling, see
parameter 46.3.
-1600.0 ... 1600.0 %
- / real32Displays the torque reference after application of reference
additive 1. See the control chain diagram on page 631.
This parameter is read-only.
Torque reference act
4
26.73
- / -Torque reference after application of reference additive 1.
For scaling, see parameter 46.3.
-1600.0 ... 1600.0 %
- / real32Displays the torque reference after limiting and ramping.
See the control chain diagram on page 631.
This parameter is read-only.
Torque ref ramp out26.74
- / -Torque reference after limiting and ramping. For scaling,
see parameter 46.3.
-1600.0 ... 1600.0 %
- / real32Displays the torque reference after control mode selection.
See the control chain diagram on page 633.
This parameter is read-only.
Torque reference act
5
26.75
- / -Torque reference after control mode selection. For scaling,
see parameter 46.3.
-1600.0 ... 1600.0 %
- / real32Displays the torque reference after application of reference
additive 2. See the control chain diagram on page 633.
This parameter is read-only.
Torque reference act
6
26.76
- / -Torque reference after application of reference additive 2.
For scaling, see parameter 46.3.
-1600.0 ... 1600.0 %
- / real32Displays the value of the source of torque reference
additive 2. See the control chain diagram on page 633.
This parameter is read-only.
Torque ref add A
actual
26.77
Parameters 303
