Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
0 / uint32Defines the maximum number of automatic resets that the
drive is allowed to attempt within the time specified by
31.15 Total trials time.
If the fault persists, subsequent reset attempts will be made
at intervals defined by 31.16 Delay time.
The faults to be automatically reset are defined by 31.12
Autoreset selection.
Number of trials31.14
1 = 1 / 1 = 1Number of automatic resets.0...5
30.0 s / real32Defines a time window for automatic fault resets. The
maximum number of attempts made during any period of
this length is defined by 31.14 Number of trials.
Note: If the fault condition remains and cannot be reset,
each reset attempt will generate an event and start a new
time window. In practice, if the specified number of resets
(31.14) at specified intervals (31.16) take longer than the
value of 31.15, the drive will continue to attempt resetting
the fault until the cause is eventually removed.
Total trials time31.15
10 = 1 s / 10 = 1 sTime for automatic resets.1.0 ... 600.0 s
0.0 s / real32Defines the time that the drive will wait after a fault (or a
previous reset attempt) before attempting an automatic
reset.
See parameter 31.12 Autoreset selection.
Delay time31.16
10 = 1 s / 10 = 1 sAutoreset delay.0.0 ... 120.0 s
Fault / uint16Selects how the drive reacts when a motor phase loss is
detected.
Note: The drive may not be able to reliably detect a phase
loss in a multimotor application: a separate protection
method (eg. a motor protection switch) should be installed
for each motor.
Motor phase loss31.19
0No action taken.No action
1
The drive trips on fault 3381 Output phase loss.
Fault
Fault / uint16Selects how the drive reacts when an earth fault or current
unbalance is detected in the motor or the motor cable.
See also section Earth (Ground) fault detection (parameter
31.20) (page 97).
Earth fault31.20
0No action taken.No action
1
The drive generates an A2B3 Earth leakage warning.
Warning
2
The drive trips on fault 2330 Earth leakage.
Fault
Parameters 333
