What to doCause
Event name /
Aux. code
Code
(hex)
Check the source of the fault (parameter
32.27 Supervision 3 signal).
Fault generated by the signal supervision
3 function.
Signal
supervision 3
80B2
Check fan feedback. See parameters
206.30…206.33 for individual failing fans.
Fan speed is under limit (parameter
206.07).
Fan speed8E12
See the auxiliary code for incompatible
CIO-01 module. Auxiliary code is a bit
Communication services of the CIO-01
module are incompatible with the
firmware version on the control unit.
I/O module
version
mismatch
8E13
word where bit 0 indicates CIO-01
module assigned to node ID 1.
Replace the incompatible CIO-01
module.
Check miniature circuit breaker and
digital input DI5.
Fault related to miniature circuit breaker.
Some of the bits of the MCB status word
are 0.
CIO MCB
monitoring
8E14
Check fuses and digital input DI6.Fault related to fuses. Some of the bits
of the fuse status word are 0.
CIO fuse
monitoring
8E15
Check digital input DI8.Fault related to digital input DI8.CIO DI8
monitoring
8E17
Check the external device.Fault in external device 1.External fault 19081
Check setting of parameter 31.1 External
event 1 source.
Check the external device.Fault in external device 2.External fault 29082
Check setting of parameter 31.3 External
event 2 source.
Check the external device.Fault in external device 3.External fault 39083
Check setting of parameter 31.5 External
event 3 source.
Check the external device.Fault in external device 4.External fault 49084
Check setting of parameter 31.7 External
event 4 source.
Check the external device.Fault in external device 5.External fault 59085
Check setting of parameter 31.9 External
event 5 source.
Informative warning. (See parameter
99.13 ID run requested.)
Current offset and gain measurement
calibration will occur at next start.
Current
calibration
A2A1
Check there are no power factor
correction capacitors or surge absorbers
in motor cable.
Drive has detected load unbalance
typically due to earth fault in motor or
motor cable.
Earth leakageA2B3
Check for an earth fault in motor or motor
cables by measuring the insulation
resistances of motor and motor cable.
Try running the motor in scalar control
mode if allowed. (See parameter 99.4
Motor control mode.)
If no earth fault can be detected, contact
your local ABB representative.
Check motor and motor cable for cabling
errors.
Short-circuit in motor cable(s) or motor.Short circuitA2B4
558 Fault tracing
