Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
6Channel B on FDCO module in slot 3.Slot 3B
10Channel 0 on RDCO module (with BCU control unit only).RDCO CH 0
7Connector XD2D.XD2D
1 / uint16Selects the node address of the drive for communication
with the external controller. No two nodes on-line may have
the same address.
With an AC 800M (CI858) DriveBus connection, drives
must be addressed 1…24; with an AC 80 DriveBus
connection, drives must be addressed 1…12. Note that
the BusManager function must be disabled in the DriveBus
controller.
With optical ModuleBus, the drive address is set according
to the position value as follows:
1. Multiply the hundreds of the position value by 16.
2. Add the tens and ones of the position value to the
result.
For example, if the position value is 101, this parameter
must be set to 1×16 + 1 = 17.
DDCS controller node
address
60.52
- / -Node address.1...254
Star / uint16Selects the topology of the fiber optic link with an external
controller.
DDCS controller HW
connection
60.55
0The devices are connected in a ring topology. Forwarding
of messages is enabled.
Ring
1The devices are connected in a star topology (for example,
through a branching unit). Forwarding of messages is
disabled.
Star
4 mbps / uint16Selects the communication speed of the channel selected
by parameter 60.51 DDCS controller comm port.
DDCS controller baud
rate
60.56
11 megabit/second.1 mbps
22 megabit/second.2 mbps
44 megabit/second.4 mbps
88 megabit/second.8 mbps
10 / uint16Defines the light intensity of the transmission LED of RDCO
module channel CH0. (This parameter is effective only
when parameter 60.51 DDCS controller comm port is set
to RDCO CH 0. FDCO modules have a hardware
transmitter current selector.)
In general, use higher values with longer fiber optic cables.
The maximum setting is applicable to the maximum length
of the fiber optic link. See Master/follower
functionality (page 34).
DDCS controller link
control
60.57
- / -Light intensity.1...15
