Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / -Data to be sent as word 1 of data set 13.0...65535
…………
- / uint16Displays (in integer format) the data to be sent to the
external controller as word 3 of data set 25.
If no data has been selected by 61.74 Data set 25 data 3
selection, the value to be sent can be written directly into
this parameter.
Data set 25 data 3
value
61.124
- / -Data to be sent as word 3 of data set 25.0...65535
LSU CW / uint32
(Parameters 61.151…61.203 only visible when supply unit
control activated by 95.20)
Parameters 61.151…61.153 preselect data to be sent in
data set 10 to another converter (typically the supply unit
of the drive).
Parameters 61.201…61.203 display the data to be sent to
the other converter. If no data has been preselected, the
value to be sent can be written directly into these
parameters.
For example, this parameter preselects the data for word
1 of data set 10. Parameter 61.201 INU-LSU data set 10
data 1 value displays the selected data in integer format.
If no data is preselected, the value to be sent can be written
directly into parameter 61.201.
INU-LSU data set 10
data 1 sel
61.151
0None.None
22Control word for the supply unit.LSU CW
24084
94.20 DC voltage reference (page 497).
DC voltage reference
24094
94.30 Reactive power reference (page 497).
Reactive power
reference
See Terms and abbreviations (page 132).
Other
DC voltage reference
/ uint32
Preselects the data to be sent as word 2 of data set 10 to
the other converter.
See also parameter 61.202 INU-LSU data set 10 data 2
value.
For the selections, see parameter 61.151 INU-LSU data
set 10 data 1 sel.
INU-LSU data set 10
data 2 sel
61.152
Reactive power
reference / uint32
Preselects the data to be sent as word 3 of data set 10 to
the other converter.
See also parameter 61.203 INU-LSU data set 10 data 3
value.
For the selections, see parameter 61.151 INU-LSU data
set 10 data 1 sel.
INU-LSU data set 10
data 3 sel
61.153
- / uint16Displays (in integer format) the data to be sent to the other
converter as word 1 of data set 10.
If no data has been preselected by 61.151 INU-LSU data
set 10 data 1 sel, the value to be sent can be written
directly into this parameter.
INU-LSU data set 10
data 1 value
61.201
- / -Data to be sent as word 1 of data set 10.0...65535
460 Parameters
