Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
3Channel A: Falling edges are used for speed calculation.
*Channel B: Defines the direction of rotation.
A falling
4One of the above modes is selected automatically
depending on the pulse frequency as follows:
Used mode
Pulse frequency of the
channel(s)
A&B all
< 2442 Hz
A all
2442…4884 Hz
A rising
> 4884 Hz
Auto rising
5One of the above modes is selected automatically
depending on the pulse frequency as follows:
Used mode
Pulse frequency of the
channel(s)
A&B all
< 2442 Hz
A all
2442…4884 Hz
A falling
> 4884 Hz
Auto falling
0 / uint16
(Visible when 92.1 Encoder 1 type = Absolute encoder)
Defines the number of bits used to indicate position within
one revolution. For example, a setting of 15 bits
corresponds to 32768 positions per revolution.
The value is used when parameter 92.11 Absolute position
source is set to EnDat, Hiperface or SSI. When parameter
92.11 Absolute position source is set to Tamagawa, this
parameter is internally set to 17.
Note: With an EnDat or HIPERFACE encoder and FEN-11
FPGA version VIE12200 or later, this parameter is
automatically set upon validation of encoder settings (91.10
Encoder parameter refresh).
Position data width92.13
1 = 1 / 1 = 1Number of bits used in position indication within one
revolution.
0...32
Enable / uint16
(Visible when 92.1 Encoder 1 type = HTL 1)
Selects whether position estimation is used with encoder
1 to increase position data resolution or not.
Position estimation
enable
92.13
0Measured position used. (The resolution is 4 × pulses per
revolution for quadrature encoders, 2 × pulses per
revolution for single-track encoders.)
Disable
1Estimated position used. (Uses position interpolation;
extrapolated at the time of data request.)
Enable
488 Parameters
