Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
1 = An ABB sine filter is connected to the output of the
drive/inverter.
ABB sine filterb1
1 = Minimum switching frequency limit adaptation to output
frequency active. This setting improves control performance
at high output frequencies (typically above 120 Hz.
High speed modeb2
1 = A custom sine filter is connected to the output of the
drive/inverter. See also parameters 97.1, 97.2, 99.18,
99.19.
Custom sine filterb3
Reservedb4…15
1 = 10000h…FFFFh
Off / uint32
(Only visible with a BCU control unit)
Enables/disables router mode of the BCU control unit.
When router mode is active, the PSL2 channels connected
to another BCU (ie. those selected by 95.17 Router channel
config) are routed to the power units (converter modules)
connected to this BCU.
See section Router mode for BCU control unit (page 108).
Note: This parameter cannot be changed while the drive
is running.
Router mode95.16
0Router mode inactive.Off
1Router mode active.On
See Terms and abbreviations (page 132).
Other [bit]
- / uint16
(Only visible with a BCU control unit)
Selects which PSL2 channels on the BCU control unit are
connected to another BCU and routed to a local power
unit.
Note: The local power units are to be connected to
successive channels starting from CH1. The other BCU is
then connected to one or more successive channels
starting from the first free channel.
Note: The lowest channel selected in this parameter is
routed to the local power unit with the lowest number, etc.
Note: There must be at least as many local power modules
as there are routed channels.
Note: This parameter cannot be changed while the drive
is running.
See section Router mode for BCU control unit (page 108).
Router channel config95.17
0ch1b0
1 = Channel CH2 is routed to the local power unit (which
is connected to CH1)
ch2b1
1 = Channel CH3 is routed to the local power unit (which
is connected to CH1)
ch3b2
1 = Channel CH4 is routed to a local power unitch4b3
1 = Channel CH5 is routed to a local power unitch5b4
1 = Channel CH6 is routed to a local power unitch6b5
1 = Channel CH7 is routed to a local power unitch7b6
Parameters 503
