KNX control elements and application parameters
Application "Scene actuator"
Product manual 2CKA00xx73xxxxx
194
– 1-byte value [0 - 100%]: A value is sent as 1-byte percentage value. The following
supplementary parameter is available:
Value for object x:
Options: Setting option from 0 - 100
– 1-byte value [0 - 255]: A value is sent as 1-byte value without a sign, e.g. actuating value,
angle or brightness value. The following supplementary parameter is available:
Value for object x:
Options: Setting option from 0 - 255
– RGB colour: A colour value is sent as 1-byte value. The following supplementary parameter
is available:
Value for object x:
Options: Setting option from 000;000;000 - 255;255;255
The entered colour value (red, green, blue) is displayed as colour pattern next to the
parameter.
