KNX control elements and application parameters
Application "Logical functions"
Product manual 2CKA00xx73xxxxx
205
Object type input/output:
Options: Switch
Forced operation
1-byte value [0% - 100%]
1-byte value [0 - 255]
1-byte value [-128 - 127]
Scene number
RTC operating mode
Temperature
2-byte value [-32768 - +32767]
2-byte value [0 - 65535]
2-byte floating point
4-byte value [-2147483648 - 2147483647]
4-byte value [0 - 4294967295]
14-byte text
The parameter is used to specify the size of the communication object.
– Switch: The following supplementary parameters are available:
Inverting an input:
Options: Deactivated
Activated
The parameter is used to specify whether the switching input is inverted.
Filter function:
Options: Do not filter
Filter 0
Filter 1
See the explanation above.
– Forced operation: Management systems can access the device directly via KNX.
However, it can also be specified that one can select manually (forced operation) via
buttons. No additional parameters available.
– 1-byte value [0% - 100%]: A value is sent as 1-byte value without a sign (percentage
value). No additional parameters available.
– 1-byte value [0 - 255]: A value is sent as 1-byte value without a sign, e.g. actuating
value, angle or brightness value. No additional parameters available.
– 1-byte value [-128 - 127]: A value is sent as 1-byte value with a sign, e.g. actuating
value. No additional parameters available.
– Scene number: The parameter is used to link the channel with a scene number. No
additional parameters available.
– RTC operating mode: After actuating the control element the device switches to the
parameterized operating mode. No additional parameters available.
– Temperature: After the control element is actuated, the device sends the parameterized
temperature value. No additional parameters available.
– 2-byte value [-32768 - +32767]: A value is sent as 2-byte value with a sign, e.g.
actuating value or time difference. No additional parameters available.
